Main SP Tables-4
SM Appendix 3-257 D117/D118
Appendix:
SP Mode
Tables
3.4 MAIN SP TABLES-4
3.4.1 SP4-XXX (SCANNER)
4008
[Sub Scan Mag.Adjustment]
Adjusts the sub-scan magnification by changing the scanner motor speed.
001
Sub Scan
Mag.Adjustment
*ENG [-1.0 to 1.0 / 0.0 / 0.1%/step]
4010
[L-Edge Regist Adjustment]
Adjusts the leading edge registration by changing the scanning start timing in
the sub-scan direction.
001 L-Edge Regist Adjustment *ENG [-1.0 to 1.0 / 0.0 / 0.1mm/step]
4011
[S-to-S Regist Adjustment]
Adjusts the side-to-side registration by changing the scanning start timing in the
main scan direction.
001 S-to-S Regist Adjustment *ENG [-2.0 to 2.0 / 0.0 / 0.1mm/step]
4012
[Scanner Erase Margin: Scale]
Sets the blank margin at each side for erasing the original shadow caused by
the gap between the original and the scale.
001 Book: Leading Edge *ENG [0.0 to 3.0 / 0.0 / 0.1mm/step]
002 Book: Trailing Edge *ENG [0.0 to 3.0 / 0.0 / 0.1mm/step]
003 Book: Left *ENG [0.0 to 3.0 / 0.0 / 0.1mm/step]
004 Book: Right *ENG [0.0 to 3.0 / 0.0 / 0.1mm/step]
