Paper Feed
D117/D118 4-106 SM
4.12.10 BY-PASS PAPER SIZE SENSOR
1. By-pass feed unit ( p.4-100)
2. Bracket [A] (
x 2)
3. By-pass feed paper sensor with the holder [A] (
x 1)
