Ricoh D117 - Mechanical Counter Installation (Only for NA)

Optional Counter Interface Unit Type A (B870)
D117/D118 2-50 SM
 Remove the cutout from the scanner rear cover [A], and route the harness as shown
above.
11. Reassemble the machine.
 Remove the optional counter interface unit before removing the controller box.
2.8.3 MECHANICAL COUNTER INSTALLATION (ONLY FOR NA)
Installation of this unit requires the following components. Other components included in this kit
are not used for installation on this machine.
No. Description Q’ty
1 Mechanical Counter 1
2 Harness 1
