Main SP Tables-2
D117/D118 3-182 SM Appendix
2690
[ITB Contact Setting]
Sets the image transfer belt contact for each paper.
001 Thick1 *ENG
[0 or 1 / 0 / 1/step]
002 Thick2 *ENG
003 Thick3 *ENG
014 Special4 *ENG
015 Special5 *ENG
016 Special6 *ENG
2900 [Drum Idling Time]
001 Standard Speed *ENG
[0 to 30 / 0 / 1s/step]
003 Low Speed *ENG
2901
[Fus.Reload:DrumIdleTimeOffset]
Offset coverage for idling rotation time of drum when fusing down reloads.
001 Coverage:0-6% *ENG [-60 to 300 / 0 / 1sec/step]
002 Coverage:6-10% *ENG [-60 to 300 / -11 / 1sec/step]
003 Coverage:10-20% *ENG [-60 to 300 / -26/ 1sec/step]
004 Coverage:20-40% *ENG [-60 to 300 / -21 / 1sec/step]
005 Coverage:40%over *ENG [-60 to 300 / -21 / 1sec/step]
