SC Tables
SM 6-49 D117/D118
Troubleshooti
ng
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
1. Reinstall the controller system software.
2. Replace the RAM-DIMM.
3. Replace the controller.
[50A1]
Video bridge device (ASIC) error 1
The CPU does not detect the video bridge device.
 Defective I/F between the video bridge device and controller
[50A2]
Video bridge device (ASIC) register error 1
The CPU detects the video bridge device, but detects error data from
the video bridge device.
 Defective I/F between the video bridge device and controller
 For more details about this SC code error, execute SP5990 to print an SMC report so you
can read the error code. The error code is not displayed on the operation panel.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
822
CTL
D
Self-diagnostic error: HDD
[XXXX]: Detailed error code
[3003]
Check performed only when HDD is installed:
 HDD device busy for over 31 s.
 After a diagnostic command is set for the HDD, but the device
remains busy for over 6 s.
 HDD defective
 HDD harness disconnected, defective
 Controller board defective
[3004]
No response to the self-diagnostic command from the ASIC to the
HDDs.
 HDD defective
