Ricoh P C301W Field Service Manual

5.System Maintenance
129
Menu
Description
[-5 to 5 / 0 / 0.1mm/step]
Vert.Tray2
Adjusts the vertical registration for tray 2.
[0 to 5 / 0 / 0.1mm/step]
Horiz Bypass Tray
Adjusts the horizontal registration for the
bypass tray.
[-5 to 5 / 0 / 0.1mm/step]
Vert Bypass Tray
Adjusts the vertical registration for the
bypass tray.
[0 to 5 / 0 / 0.1mm/step]
Horiz.Dup. Back
Adjusts the horizontal registration for the
back side in duplex mode.
[-5 to 5 / 0 / 0.1mm/step]
Vert.Dup. Back
Adjusts the vertical registration for the
back side in duplex mode.
[0 to 5 / 0 / 0.1mm/step]
Destination
Sets the destination and updates the
engine setting.
[DOM / NA (Default) / EU / CHN /
TAIWAN / ASIA]
Model Name
Displays the current model in a dropdown
list.
Do not change this setting (DFU).
2nd Transfer
Media Type
Selects the media type in order to set the
paper transfer current.
“2nd Front” and “2nd Back” are the only
features affected by the settings for the
selected "Media Type".
• Thin Paper
• Plain Paper 1
• Plain Paper 2
• Middle Thick Paper
• Recycled Paper
• Color Paper
• Letterhead
• Preprinted Paper
• Prepunched Paper
• Label Paper
• Bond Paper

Ricoh P C301W Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	256 MB
Built-in processor	-
Sound pressure level (printing)	- dB
Cables included	AC
Included cartridge capacity (black)	1000 pages
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
Weight	25000 g
