5.System Maintenance
156
Menu
Description
0: Set, 1: Not set
Bank:Paper End
Detection
Displays the bank paper end
sensor status.
0: Paper present, 1: No paper
Bank:Set Sensor
Displays the bank set status.
0: Set, 1: Not set
Bank:Transport Sensor
Displays the bank transport sensor
status.
0: No paper, 1: Paper present
Drum Motor FCLock
Displays the color drum motor lock
signal.
0: Rotate, 1: At rest or lock
Transf. Drum Motor
KLock
Displays the black drum motor lock
signal.
0: Rotate, 1: At rest or lock
Fusing Motor: Lock
Displays the fusing motor lock
signal.
0: Rotate, 1: At rest or lock
HVP:SC Detection
Displays the HVPS abnormally
detection signal.
0: Abnormal, 1: Normal
Interlock Release
Detect./1
Displays the interlock 1 status.
0: Door open, 1: Door closed
Interlock Release
Detect./2
Displays the interlock 2 status.
0: Door open, 1: Door closed
Fault Detection
Displays the failure status in order
of R8C, registration clutch, paper
feed clutch, bank feed clutch, bank
transport clutch, duplex motor.
0: Abnormal, 1: Normal
OUTPUT Check
Only one part can be
turned ON at a time.
ITB Contact Motor:CW
Rotates the ITB contact motor.
Waste Toner Motor
Rotates the waste toner collection
motor.
Drum Mot. FC: Low
Rotates the color drum motor.
Drum Mot. FC:
Standard
Transf. Drum Mot. K:
Rotates the black drum motor.
