Ricoh P C301W Field Service Manual

7.Detailed Descriptions
278
shutdown, replace the fusing unit with a new unit.
SC No.
SC name
Monitored location
Conditions
SC543-
00
Fusing thermopile high temperature detected
(Software)
Fusing sleeve belt
(center) surface
240°C
SC544-
00
Fusing thermopile high temperature detected
(Hardware)
Fusing sleeve belt
(center) surface
250 to
260°C
SC554-
00
Fusing NC sensor high temperature detected
(Hardware)
Fusing sleeve belt
(center) surface
400 to
410°C
SC563-
00
Pressure roller thermistor (center) high
temperature detected (Software)
Pressure roller (center)
surface
248°C
SC564-
00
Pressure roller thermistor (center) high
temperature detected (Hardware)
Pressure roller (center)
surface
240 to
260°C
SC573-
00
Pressure roller thermistor (end) high
temperature detected (Software)
Pressure roller (end)
surface
248°C
SC574-
00
Pressure roller thermistor (end) high
temperature detected (Hardware)
Pressure roller (end)
surface
240 to
260°C
None
Fusing thermostat detected high temperature
Temperature of fusing
thermostat
185±3°C
Fusing Modes
Warm-up Mode
The machine enters the warm-up mode after the machine turned on. Turning the machine power on
lights the fusing lamp which raises the heat in the fusing unit to the Reload Temperature. After the
fusing unit has warmed up, the fusing motor rotates for a prescribed time to maintain the target Reload
Temperature.
Standby Mode
Within the prescribed time after the machine has reached Reload Temperature, electrical power to the
fusing lamp is switched off, and then the fusing motor switches off.
Then the fusing lamp will intermittently switch on and off in order to maintain the target Standby
Temperature. In Standby Mode the fusing motor is also switched ON/OFF intermittently.
Ready Mode
When returning from Standby Mode, the machine switches on the fusing lamp until the fusing
temperature is raised to the target Ready Temperature.
If there is no print job request issued within the prescribed time, the machine will drop down again into
Standby Mode. If the machine sends a print job request in the Standby Mode, the fusing lamp switches
on until the fusing unit reaches the target Reload Temperature, and then the job starts.

Ricoh P C301W Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	256 MB
Built-in processor	-
Sound pressure level (printing)	- dB
Cables included	AC
Included cartridge capacity (black)	1000 pages
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
Weight	25000 g
