Roche cobas b 123 User Manual

Roche Diagnostics
Instructions for Use · Version 13.0 45
cobas b 123 POC system 2 General description
Consumable information
Glu/Lac sensors
Glu/Lac sensors measure glucose and lactate.
Figure 2-22 Glu/Lac sensors
Glucose sensor Glucose oxidizes to form gluconolacton using atmospheric oxygen and the glucose-
oxidase enzyme. The generated H
2
O
2
is determined amperometrically by using the
manganese dioxide/carbon electrode at 350 mV.
Lactate sensor Lactate oxidizes to form pyruvate using the lactate-oxidase enzyme. The generated
H
2
O
2
is determined amperometrically by using the manganese dioxide/carbon
electrode at 350 mV.
A BSA sensor E Glucose reference sensor
B Lactate counter electrode F Glucose sensor
C Lactate sensor G Glucose counter electrode
D Lactate reference sensor H Conductivity contact
A
C
B
F
D
G
E
H
