2 General description cobas b 123 POC system
Consumable information
Figure 2-25 Sample sensor contacts
q
Do not touch the sample sensor contacts on the Fluid Pack.
Sample input module The fill port aspirates samples from syringes, capillaries,
Roche MICROSAMPLER PROTECT, and ampoule adapters.
Figure 2-26 Sample input module
A Sample sensor contacts on the Fluid Pack B Sample sensor contacts inside the
measuring chamber module
A
B
A Sample input module B Fill port (capillary position) C Fill port (syringe position)
B
C
