Media-Store
Media-Store allows you to load stills or animations from
the hard drive and make them available as a source on
the switcher. The switcher provides two types of
media-store, ME-Store and Global-Store.
The Global-Store consists of up to 4 dedicated channels
of media-store that are available as inputs to all MEs and
Aux Buses of the switcher. The fourth channel of
Global-Store can be enabled from the Personality menu
(Global-Store 4 Mode). All channels can be used
independently, or two can be tied together to provide
separate ll and alpha channels. The 4 Gigabytes of
Global-Store cache is provided from Frame CPU board.
The ME-Store option consists of 4 channels of
media-store that are available as inputs to the ME they
have been installed for and can be re-entered onto any
other ME in the switcher. Each ME can have 4
independent channels of ME-Store. The 8 Gigabytes of
ME-Store cache is provided from the 3G Video Processor
board. If the ME is congured as a MultiViewer, the
ME-Stores for that ME are congured as MV-Stores
(MultiViewer Stores) with the same functionality.
In addition to the video channels of the Global-Store, an
additional set of audio channels are provided. The number
of audio channels matches the video channels and can
be increased from three to four from the Personality menu
(Global-Store 4 Mode). Audio and Video playout are
independent from each other.
Media-Store allows you to load stills or animations from
the hard drive and make them available as a source on
the switcher. The switcher provides two types of
media-store, ME-Store and Global-Store.
The Global-Store consists of 1 dedicated channel of
media-store (video+alpha) that is available as an input
to all MEs and Aux Buses of the switcher. The 4
Gigabytes of Global-Store cache is provided from Frame
CPU board.
The ME-Store option consists of 2 channels of
media-store (video+alpha) that are available as inputs to
the ME they have been installed for and can be re-entered
onto any other ME in the switcher. The 8 Gigabytes of
ME-Store cache per ME is provided from the 3G Video
Processor board. If the ME is congured as a
MultiViewer, the ME-Stores for that ME are congured
as MV-Stores (MultiViewer Stores) with the same
functionality.
In addition to the video channels of the Global-Store, an
additional set of audio channels are provided.
Keep the following in mind:
Keep the following in mind when you are using the
Media-Store:
• If you know the number of the still you want to load,
you can select the crosspoint button mapped to the
still-store channel on the ME, and then enter the still
number on the keypad on the Global Memory module.
• You can clear the still currently loaded into a channel
by selecting 0 as the still number you load from the
keypad on the Global Memory module. This is the
same as pressing the Eject button.
• If you are loading an Auto Key (PNG or TGA with
alpha) into a media-store channel, you must have
another media-store channel associated with the
current one to load the alpha into.
• Corrupt les are shown with the warning Not a
valid image format and should be deleted
from the switcher.
• Using a third-party application to upload, edit, or
move media items or directories on the switcher can
cause the permissions to those les or directories to
be set incorrectly. Use the Media-Store Permissions
feature from the Web UI to clean the permissions.
• MV-Stores are always available when the ME is
congured as a MultiViewer, even if you do not have
permissions to that ME.
• In SD/HD video formats there are up to 4 channels
of Global-Store and 4 channels of ME-Store (per
ME). In UHDTV1 video formats, there is 1 channel
of Global-Store and 2 channels of ME-Store. In
UHDTV1 each channel includes a video and alpha
sub-channel.
• If the switcher is operating in a UHDTV1 video
format, only 1 MV-Store channel (video plus alpha)
is available for each video processor. For example,
for MultiViewer 3 and 4, only MV-Store 3 channels
1 is available.
• Media items should be created in the same color
gamut and dynamic range that they are intended to
be used in on the switcher.
File Specifications
Media les must meet the following specication for use
in the media-stores.
Table 11: Video File Specifications
SpecificationParameter
Targa (.tga)File Type
Portable Network Graphics
(.png)
JPEG (.jpg or .jpeg)
Acuity Operation Manual (v9.2) — Media-Store • 73
