Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
5
Input/output (I/O) modules
5-129
Motion control modules for servo-motors
Encoder inputs for modules PCD2.H320 and PCD2.H322
Axis 1 Axis 2
Inputs A B IN A B IN
Number of inputs 3 3
Input voltage (typical) 24 V 24 V
Signal state L (Low) -30 … +5 V -30 … +5 V
Signal state H (High) +15 … +32 V +15 … +32 V
Input current (typical) H320
H322
7 mA
7 mA
7mA
2mA
Source operation (positive logic) x x
F
max
125 kHz
1)
125 kHz
1)
1)
Internal counting frequency 500 kHz
Encoder inputs for modules PCD2.H325 and PCD2.H327
Axis 1 Axis 2
Inputs A,/A B,/B IN,/IN A,/A B,/B IN,/IN
Number of inputs 6 6
Input voltage (typical) RS-422 RS-422
Input impedance (typical) H325
H327
150 Ω
150 Ω
150 Ω
1500 Ω
F
max
250 kHz
1)
250 kHz
1)
1)
Internal counting frequency 1 MHz
5 V supply for 5 V encoder modules PCD2.H325 and PCD2.H327
Short circuit protection Yes
Electrical isolation No
Output voltage 5 V
Max. load current 300 mA
Short circuit current 400 mA
Overvoltage protection TVS diode 39 V +/- 10 %
Reverse voltage protection No
Power supply to all modules
Internal current consumption:
from +5 V bus (without en-
coder)
typically 210 mA, max. 230 mA
(250 mA in SSI operation)
Internal current consumption:
from V+ bus (without encoder)
15 … 20 mA
External current consumption: 0 … 2 mA (without load current)
1 A for outputs
Total current consumption for all I/O modules including encoders must not exceed 1.6 A.
PCD2.H32x modules should be plugged onto the base unit wherever possible (not the ex-
pansion housing).
Operational conditions
Ambient temperature operation: 0 … +55 °C without forced ventilation,
storage: -20 … +85 °C
Noise immunity: EC mark according to EN 61 000-6-3 and EN 61 000-6-2
Programming: Based on Saia PCD
®
user program and pre-programmed
function blocks (FB).
Terminals: Pluggable 10-pole spring terminal block
(4 405 4847 0), for wires up to 1.5 mm²
