Date Code 20010719 701 Motor Protection Relay
ASCII Serial Port Operation
Command Summary
6.9
The serial port command explanations that follow in the Command Explanations
subsection are in alphabetical order.
Table 6.4 SEL-701 Serial Port Command Summary (Continued)
Access
Level
Serial Port
Command
Command Description
Page Number
Event Analysis Commands
1 EVENT View event reports 6.13
1 HISTORY View event summaries/histories 6.13
2 HISTORY R Reset event history data 6.14
1 SER View sequential events recorder data 6.21
2 SER R Reset sequential events recorder data 6.22
1 TARGET Display relay element status 6.27
1 TARGET R Reset target LEDs 6.30
1 TRIGGER Trigger an event report 6.31
Motor Data Commands
1 LDP Display load profile data 6.14
1 LDP D Display load profile buffer size 6.15
2 LDP R Reset load profile data 6.15
1 MOTOR Display motor statistics 6.18
2 MOTOR R Reset motor statistics 6.19
1 MSR Display motor start reports 6.19
1 MSR F Display the format of a motor start report 6.19
1 MST Display motor start trend data 6.19
2 MST R Reset motor start trend data 6.19
2 RLP Reset learned motor parameters 6.21
Relay Setting Commands
1 SHOW Show/view relay settings 6.24
2 SET Enter/change relay settings 6.22
Relay Output Control Commands
2 ANALOG Test analog output 6.11
2 CON Control remote bit 6.12
2 PUL Pulse output contact 6.20
2 STOP Stop motor 6.27
2 STR Start motor 6.27
