701 Motor Protection Relay Date Code 20010719
SEL-2020/2030 & SEL-701PC Compatibility Features
CEVENT Command
D.26
CEVENT Command
Display event report in compressed ASCII format by sending:
CEV n
where:
n event number (1–n), defaults to 1.
The relay responds to the CEV command with the nth event report as shown
below. The relay replaces the items in italics with the actual relay data.
The SEL-701 Relay sends:
<STX>"FID","yyyy"<CR>
"Relay FID string","yyyy"<CR>
"MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
"FREQ","SAM/CYC_A","SAM/CYC_D","NUM_OF_CYC","TYPE","IA","IB","IC","IN","IG","3I2","UB_CURR(%)","
THM CAP(%)","VAB","VBC","VCA","kW","kVAR","kVA","PF","LEAD/LAG","WINDING (C)","BEARING
(C)","AMBIENT (C)","OTHER (C)","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,"xxxx",xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx
,xxxx,"xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"IA","IB","IC","IG","IN","VAB","VBC","VCA","TRIG ","Names of elements in the Relay Word
separated by spaces","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,z,"HEX-ASCII Relay Word","yyyy"<CR>
"SETTINGS","yyyy"<CR>
"Relay settings as displayed with the showset command (surrounded by quotes)","yyyy"<CR>
<ETX>
where:
"xxxx" are the data values corresponding to the line labels.
"yyyy" is the 4-byte hex ASCII representation of the checksum.
"FREQ" is the power system frequency at the trigger instant.
"SAM/CYC_A" is the number of analog data samples per cycle
(4 or 16).
"SAM/CYC_D" is the number of digital data samples per cycle
(4 or 16).
"NUM_OF_CYC" is the number of cycles of data in the event
report.
"TYPE" is the event type.
"TRIG" refers to the trigger record.
"IA", "IB", "IC", "IN", "IG", "3I2" are the summary currents.
"VAB", "VBC", and "VCA" are replaced by “VA ”, “VB”, and
“VC” in the event body when phase-neutral potentials are
applied. They are replaced by “*” when voltages are not
included.
"TRIG" refers to the trigger record.
