Date Code 20010719 701 Motor Protection Relay
Section 2
Installation
Panel Cut & Drill Plans
Figure 2.1 on page 2.2 shows the mechanical dimensions of the SEL-701 Relay.
Figure 2.2 on page 2.3 shows the dimensions of the panel cutout required to mount the
relay.
!
DANGER: Contact with instrument terminals may cause
electrical shock which can result in injury or death.
Guard against accidental contact with relay rear terminals by mounting the relay
in an approved enclosure or by using any of the following methods:
Locate the relay in a room, vault, or similar enclosure that is
accessible only to qualified persons.
Locate the relay on a suitable balcony, gallery, or platform that is
elevated and accessible only to qualified persons.
Use suitable permanent, substantial partitions or screens arranged so
that only qualified persons have access to the space within reach of
live parts. Locate and size any openings in partitions or screens so
that neither people nor conducting objects are likely to come into
accidental contact with live parts.
