Schweitzer Engineering Laboratories SEL-701 - Table 9.5

Date Code 20010719 701 Motor Protection Relay
Event Analysis
Event Reports
9.11
Table 9.5
Output, Input, and Element
Event Report Columns (Continued)
Column
Heading Symbol Definition
Wdg w A Winding RTD has exceeded the alarm temperature.
W One or two Winding RTDs have exceeded
the trip temperature.
Brg b A Bearing RTD has exceeded the alarm temperature.
B One or two Bearing RTDs have exceeded
the trip temperature.
Oth RTD o An Other RTD has exceeded the alarm temperature.
O One or two Other RTDs have exceeded the trip temperature.
Amb RTD a The Ambient RTD has exceeded the alarm temperature.
A The Ambient RTD has exceeded the trip temperature.
Out T1 T TRIP contact output asserted.
1 Contact output OUT1 asserted.
b Both TRIP and OUT1 asserted.
Out 23 2 Contact output OUT2 asserted.
3 Contact output OUT3 asserted.
b Both OUT2 and OUT3 asserted.
Out A A Contact output ALARM asserted.
In 12 1 Contact input IN1 asserted.
2 Contact input IN2 asserted.
b Both IN1 and IN2 asserted.
In 34 3 Contact input IN3 asserted.
4 Contact input IN4 asserted.
b Both IN3 and IN4 asserted.
In 56 5 Contact input IN5 asserted.
6 Contact input IN6 asserted.
b Both IN5 and IN6 asserted.
In 7 7 Contact input IN7 (from SEL-2600) asserted.
