701 Motor Protection Relay Date Code 20010719
SEL-2020/2030 & SEL-701PC Compatibility Features
Fast Binary Message Lists
D.2
Fast Binary Message Lists
Binary Message List
Table D.1 Binary Message List
ASCII Configuration Message List
Table D.2 ACSII Configuration M essage List
Table D.1 Binary Message List
Request to Relay Response From Relay
Hex
A5C0 Relay Definition Block
A5C1 Fast Meter Configuration Block
A5D1 Fast Meter Data Block
A5C2 Demand Fast Meter Configuration Block
A5D2 Demand Fast Meter Data Message
A5C3 Peak Demand Fast Meter Configuration Block
A5D3 Peak Demand Fast Meter Data Message
A5B9 Fast Meter Status Acknowledge
A5CE Fast Operate Configuration Block
A5E0 Fast Operate Remote Bit Control
A5E3 Fast Operate Breaker/Contactor Control
Table D.2 ASCII Configuration Message List
Request
to Relay
Response From Relay
ASCII
ID ASCII Relay Identification and Configuration Strings
DNA ASCII Names of Relay Word Bits
BNA ASCII Names of Bits in the A5B9 Status Byte
