Schweitzer Engineering Laboratories SEL-701 - 05 H Force Single Coil Command

Date Code 20010719 701 Motor Protection Relay
Modbus
®
RTU Communications Protocol
05h Force Single Coil Command
C.9
05h Force Single Coil Command
The SEL-701 Relay uses this function code for a variety of data control purposes.
Specifically, you can use it to clear archive records, operate output contacts, and
operate breaker and remote bit elements.
Table C.8 05h Force Single C oil Command
The command response is identical to the command request.
The SEL-701 Relay offers the commands listed in Ta bl e C. 9 that you can execute
using function code 05h. The command coils are self-resetting.
Table C.9 SEL- 701 Relay Co mmand Coils
Table C.8 05h Force Single Coil Command
Bytes Field
The Master Request Must Have the Following Format
1 byte Slave address
1 byte Function code (05h)
2 bytes Coil reference
1 byte Operation code (FF for bit set, 00 for bit clear)
1 byte Placeholder (00)
2 bytes CRC-16 for message
Table C.9 SEL-701 Relay Command Coils
Coil Field
1 Start
2 Stop
3 Emergency Restart
4 Reset Trip, Targets
