Date Code 20010719 701 Motor Protection Relay
Event Analysis
Example Sequential Events Recorder (SER) Report
9.19
Table 9.7 Ex ample Sequential Events Recorde r (SER) Repor t Explanations
Table 9.7
Example Sequential Events
Recorder (SER) Event Report Explanations
Item # Explanation
13, 12, 11, 10, 9, 8 After a 10-second accelerating time, the motor relay indicates
the motor is running (11). Later, the current unbalance alarm
element (46UBA, aliased as UNBALNC_I_ALARM) times out,
causing the relay to close output contact OUT1, programmed to
indicate protection element alarms (9, 8).
7, 6 The current unbalance trip element (46UBT, aliased as
UNBALNC_I_TRIP) times out, causing the relay to trip. Since
now both ouput contact OUT1 and TRIP are asserted, the relay
places a ‘b’ in the T1 output column of the event report.
5, 4, 3 Declining current due to the opening contactor allows the
unbalance detecting overcurrent elements to drop out and the
relay deasserts output contact OUT1.
2, 1 As the current continues to drop, the relay declares the motor
stopped.
