Schweitzer Engineering Laboratories SEL-701 - Figure 6.15 SHOW Command Example

Date Code 20010719 701 Motor Protection Relay
ASCII Serial Port Operation
Command Explanations
6.25
=>SHOW
Relay Settings:
RID =SEL-701
TID =MOTOR RELAY
CTR = 20 ITAP = 5 CTRN = 10 INTAP = 5
PHROT = ABC FNOM = 60 DATE_F = MDY DMTC = 15
PTR = 4 DELTA_Y = Y SINGLEV = N
SETMETH = RATING FLA = 5.00 SF = 1.15 LRA = 30.00
LRTHOT = 2.1 LRTCOLD = 2.5 TD = 1.00 TCAPU = 90
TCSTART = 85 TCLRNEN = Y COOLTIME= 259 COOLEN = Y
50P1P = OFF 50P2P = OFF 50G1P = 2.50 50G1D = 0.10
50G2P = OFF 50N1P = 2.500 50N1D = 0.10 50N2P = OFF
50QP = OFF
MAXSTART= 3 TBSDLY = 20
LJTPU = 2.0 LJTDLY = 1.00 LLAPU = OFF
46UBA = 10 46UBAD = 2.50 46UBT = 15 46UBTD = 5.00
Press RETURN to continue
E47T = Y
SPDSDLY = OFF
RTDOPT = INT TMPREF = F RTD1LOC = WDG RTD2LOC = WDG
RTD3LOC = WDG RTD4LOC = WDG RTD5LOC = WDG RTD6LOC = WDG
RTD7LOC = BRG RTD8LOC = BRG RTD9LOC = BRG RTD10LOC= BRG
RTD11LOC= AMB RTD1TY = PT100 RTD2TY = PT100 RTD3TY = PT100
RTD4TY = PT100 RTD5TY = PT100 RTD6TY = PT100 RTD7TY = NI120
RTD8TY = NI120 RTD9TY = NI100 RTD10TY = NI100 RTD11TY = PT100
TRTMP1 = 280 ALTMP1 = 250 TRTMP2 = 280 ALTMP2 = 250
TRTMP3 = 280 ALTMP3 = 250 TRTMP4 = 280 ALTMP4 = 250
TRTMP5 = 280 ALTMP5 = 250 TRTMP6 = 280 ALTMP6 = 250
TRTMP7 = OFF ALTMP7 = 199 TRTMP8 = OFF ALTMP8 = 199
TRTMP9 = OFF ALTMP9 = 199 TRTMP10 = OFF ALTMP10 = 199
TRTMP11 = OFF ALTMP11 = OFF EWDGV = Y EBRGV = N
RTDBEN = N
27P1P = OFF 27P2P = OFF
59P1P = 73 59P2P = OFF 59GP = OFF
NVARAP = OFF NVARTP = OFF
37PAP = OFF 37PTP = OFF
Press RETURN to continue
55LDAP = OFF 55LDTP = OFF
81D1P = 59.10 81D1D = 0.03 81D2P = OFF 81D3P = OFF
AOSIG = 4-20MA AOPARM = %LOAD_I
FP_TO = 15 FPBRITE = 50 FP_KW = N FP_RTD = N
DM1_1 =SEL-701 DM1_0 =
DM2_1 =MOTOR RELAY DM2_0 =
DM3_1 =RTD FAILURE DM3_0 =
DM4_1 = DM4_0 =
TRFS = Y OUT1FS = N OUT2FS = N OUT3FS = N
TDURD = 0.50 ABSDLY = 0
FACTLOG = Y
LEUSE 88.4
SETCHK 854B
=>
Figure 6.15 SHOW Command Example.
