701 Motor Protection Relay Date Code 20010719
Commissioning
Selected Functional Tests
7.16
Table 7.8 100- Ohm Platinum RT D Type (RTDs 1–6)
Table 7.9 100- Ohm Platinum RT D Type (RTDs 7–12)
Table 7.8 100-Ohm Platinum RTD Type (RTDs 1–6)
RTD Temperatures
Resistance
Value
(ohms)
Expected
Temperature
Reading
(°C)
Expected
Temperature
Reading
(°F)
1 2 3 4 5 6
80.31 –50 –58
100.00 0 32
119.39 50 122
138.50 100 212
157.32 150 302
175.84 200 392
190.45 240 464
Table 7.9 100-Ohm Platinum RTD Type (RTDs 7–12)
RTD Temperatures
Resistance
Value
(ohms)
Expected
Temperature
Reading
(°C)
Expected
Temperature
Reading
(°F)
7 8 9 10 11 12
80.31 –50 –58
100.00 0 32
119.39 50 122
138.50 100 212
157.32 150 302
175.84 200 392
190.45 240 464
