Schweitzer Engineering Laboratories SEL-701 - Command Summary; SEL-701 Serial Port Command Summary; Table 6.4

701 Motor Protection Relay Date Code 20010719
ASCII Serial Port Operation
Command Summary
6.8
Command Summary
Table 6.4 lists the serial port commands associated with particular activities. All
Access Level 1 commands are also available in Access Level 2. The commands are
shown in upper-case letters, but can also be entered with lower-case letters.
Table 6.4 SEL -701 Seria l P ort Command Sum mary
Table 6.4 SEL-701 Serial Port Command Summary
Access
Level
Serial Port
Command Command Description Page Number
Serial Port Access Commands
1 HELP Display available commands 6.10
1 2ACCESS Go to Access Level 2 6.11
2 ACCESS Go to Access Level 1 6.11
2 PASSWORD View/change password 6.20
2 QUIT Go to Access Level 1 6.21
Relay Self-Test Status Commands
1 STATUS Display relay self-test status 6.26
2 STATUS R Clear self-test status and restart relay 6.27
Relay Clock/Calendar Commands
1 DATE View/change date 6.12
1 TIME View/change time 6.30
Meter Data Commands
1 METER Display metering data 6.15
1 METER D Display demand and peak demand data 6.16
1 METER E Display energy metering data 6.16
1 METER M Display max/min metering data 6.17
1 METER T Display thermal metering data 6.17
1 METER RD Reset demand ammeter 6.18
1 METER RE Reset energy metering 6.18
1 METER RM Reset max/min metering 6.18
1 METER RP Reset peak demand ammeter 6.18
(Continued)
