Schweitzer Engineering Laboratories SEL-701 - CME T Command XXXXXX

701 Motor Protection Relay Date Code 20010719
SEL-2020/2030 & SEL-701PC Compatibility Features
CME T Command xxxxxx
D.30
CME T Command xxxxxx
Display thermal meter data in compressed ASCII format by typing:
CME T <CR>
The relay replaces the items in italics with the actual relay data.
The SEL-701 Relay sends:
<STX>"FID","yyyy"<CR>
"Relay FID string","yyyy"<CR>
"MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
"1 BRG (C)","2 BRG (C)","3 BRG (C)","4 BRG (C)","5 BRG (C)","6 BRG (C)","7 WDG (C)","8 WDG
(C)","9 WDG (C)","10 WDG (C)","11 AMB (C)","12 OTH (C)","FLA(%)","THM CAP(%)","RTD TC(%)","CALC
TIME","MINUTES","STARTS","yyyy"<CR>
"xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx",
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
<ETX>
where:
 "THM CAP(%)" is the thermal model thermal capacity used in
percent.
 "RTD TC(%)" is the RTD estimated thermal capacity used in
percent.
 "CALC TIME" is the calculated time to thermal trip in seconds.
 "MINUTES" is the number of minutes since the last motor start.
 "STARTS" is the number of motor starts in the past hour.
RTD labels are replaced with “*” if RTDs are not supported or enabled. RTD
locations and temperature designators are setting dependent. RTD thermal capacity is
reported as 0 if RTDs are not supported or enabled.
