RTD-Based Protection
4.32
RTD Type Settings
Table 4.24 RTD Type S ettings
The relay allows you to define the type of each monitored RTD independently
using the RTD Type settings.
If an RTD Location setting is equal to NONE, the relay does not request that an
RTD Type setting be entered for that input.
The four available RTD types are:
 100-ohm platinum (PT100)
 100-ohm nickel (NI100)
 120-ohm nickel (NI120)
 10-ohm copper (CU10)
Table 4.24 RTD Type Settings
Setting Prompt Setting Range
Setting Name =
Factory Default
RTD Type PT100, NI100, NI120, CU10 RTD1TY = PT100
RTD Type PT100, NI100, NI120, CU10 RTD2TY = PT100
RTD Type PT100, NI100, NI120, CU10 RTD3TY = PT100
RTD Type PT100, NI100, NI120, CU10 RTD4TY = PT100
RTD Type PT100, NI100, NI120, CU10 RTD5TY = PT100
RTD Type PT100, NI100, NI120, CU10 RTD6TY = PT100
RTD Type PT100, NI100, NI120, CU10 RTD7TY = PT100
RTD Type PT100, NI100, NI120, CU10 RTD8TY = PT100
RTD Type PT100, NI100, NI120, CU10 RTD9TY = PT100
RTD Type PT100, NI100, NI120, CU10 RTD10TY = PT100
RTD Type PT100, NI100, NI120, CU10 RTD11TY = PT100
RTD Type
a
PT100, NI100, NI120, CU10 RTD12TY = PT100
a
The twelfth RTD input is only available when you use the SEL-2600 RTD Module.
