Date Code 20010719 701 Motor Protection Relay
Metering & Monitoring
Motor Operating Statistics
8.11
=>MOTOR
SEL-701 Date: 09/01/1999 Time: 16:00:14.625
MOTOR RELAY
Operating History, elapsed time in ddd:hh:mm Since: 07/02/1999 10:56:15
Running time: > 0:01:58
Stopped time: 54:23:47
Time running: 0.1%
Total MWhr: 0.4
Number of starts: 10
Average Peak
Starting time: 7.6 10.0
Starting current (A): 2762.1 3014.0
Min starting voltage (V): 476 463
Starting % thermal capacity: 76.5 84.0
Running % thermal capacity: 60.5 68.8
Rtd % thermal capacity: 45.3 54.2
Running current (A): 70.1 75.0
Running kW: 54.9 58.4
Running kVARin: 15.2 15.7
Running kVARout: 0.9 1.3
Running kVA: 56.8 57.9
Hottest winding RTD temp (F): 145 164
Hottest bearing RTD temp (F): 95 120
Ambient RTD temp (F): 79 98
Hottest other RTD temp (F): NA
Learned Motor Parameters
Stopped Cooling Time: 486
Starting Thermal Capacity: 62
Alarms Trips
Thermal: 0 2
Locked rotor: 2 2
Load loss: 0 0
Load jam: 3
Unbalance current: 1 1
Phase fault: 0
Ground fault: 0
Speed switch: 0
Undervoltage: 0
Overvoltage: 36
Underpower: 0 0
Power factor: 0 0
Reactive power: 0 0
Phase reversal: 0
Underfrequency: 0
Overfrequency: 0
RTD: 28 0
Total: 31 44
=>
Figure 8.3 MOTOR Command Example.
