Date Code 20010719 701 Motor Protection Relay
Settings Calculation
RTD-Based Protection
4.33
RTD Alarm & Trip Temperatures
Table 4.25 RTD A la rm and Trip Temper ature Settings
Table 4.25 RTD Alarm and Trip Temperature Settings
a
Setting Prompt
Setting Range
Setting Name =
Factory Default
RTD Trip Temperature OFF, 32°–482°F TRTMP1 = OFF
RTD Alarm Temperature OFF, 32°–482°F ALTMP2 = OFF
RTD Trip Temperature OFF, 32°–482°F TRTMP2 = OFF
RTD Alarm Temperature OFF, 32°–482°F ALTMP2 = OFF
RTD Trip Temperature OFF, 32°–482°F TRTMP3 = OFF
RTD Alarm Temperature OFF, 32°–482°F ALTMP3 = OFF
RTD Trip Temperature OFF, 32°–482°F TRTMP4 = OFF
RTD Alarm Temperature OFF, 32°–482°F ALTMP4 = OFF
RTD Trip Temperature OFF, 32°–482°F TRTMP5 = OFF
RTD Alarm Temperature OFF, 32°–482°F ALTMP5 = OFF
RTD Trip Temperature OFF, 32°–482°F TRTMP6 = OFF
RTD Alarm Temperature OFF, 32°–482°F ALTMP6 = OFF
RTD Trip Temperature OFF, 32°–482°F TRTMP7 = OFF
RTD Alarm Temperature OFF, 32°–482°F ALTMP7 = OFF
RTD Trip Temperature OFF, 32°–482°F TRTMP8 = OFF
RTD Alarm Temperature OFF, 32°–482°F ALTMP8 = OFF
RTD Trip Temperature OFF, 32°–482°F TRTMP9 = OFF
RTD Alarm Temperature OFF, 32°–482°F ALTMP9 = OFF
RTD Trip Temperature OFF, 32°–482°F TRTMP10 = OFF
RTD Alarm Temperature OFF, 32°–482°F ALTMP10 = OFF
RTD Trip Temperature OFF, 32°–482°F TRTMP11 = OFF
RTD Alarm Temperature OFF, 32°–482°F ALTMP11 = OFF
RTD Trip Temperature
b
OFF, 32°–482°F TRTMP12 = OFF
RTD Alarm Temperature
b
OFF, 32°–482°F ALTMP12 = OFF
Enable Winding Trip Voting Y, N EWNDGV = N
Enable Bearing Trip Voting Y, N EBRNGV = N
Enable RTD Biasing Y, N RTDBEN = Y
a
Note: When the TEMPREF setting equals C, the trip and alarm temperature setting ranges
above are OFF, 0°-250°C.
b
The twelfth RTD input is only available when you use the SEL-2600 RTD Module.
