Schweitzer Engineering Laboratories SEL-701 - RTD Input Status Messages; Table 8.5; Energy Meter Values

Date Code 20010719 701 Motor Protection Relay
Metering & Monitoring
Introduction
8.5
Table 8.5 RTD Inp ut Status Mess ages
Energy Metering
Table 8.6 En ergy Meter Values
When voltage inputs are selected and connected, the relay records the real,
reactive, and apparent energy consumed by the motor.
Table 8.5 RTD Input Status Messages
Message Status
Open RTD leads open
Short RTD leads shorted
Comm. Fail Fiber-optic communications to
SEL-2600 RTD Module have failed
Stat Fail SEL-2600 RTD Module self-test status failure
Table 8.6 Energy Meter Values
Relay Option Energy Values
Without Voltage
Inputs (Relay
Models 0701000
and 0701010)
None
With Voltage
Inputs (Relay
Models 0701001
and 0701011)
MWhr, MVARhr-in, MVARhr-out, and MVAhr Magnitudes
