Date Code 20010719 701 Motor Protection Relay
Modbus
®
RTU Communications Protocol
Modbus Register Map
C.19
Modbus Register Map
Table C.18 Modbus Regi ster Map
Table C.18 Modbus Register Map
Address
(hex)
Field
Sample
Low
High
Step
Type
PRODUCT ID
0000 FID FID string
0001
0002
0003
0004
0005
0006
0007
0008
0009
000A
000B
000C
000D
000E
000F
0010
0011
0012
0013
0014
0015 Reserved
0016 Reserved
0017 Revision R100
0018
0019 Reserved
001A Relay ID SEL-701
001B
001C
(Continued)
