701 Motor Protection Relay Date Code 20010719

Modbus

RTU Communications Protocol

Modbus Register Map

C.20

Table C.18 Modbus Register Map (Continued)

Address

(hex)

Field

Sample

Low

High

Step

Type

001D

001E

001F

0020

0021

0022

0023

0024 Reserved

0025 Terminal ID

MOTOR

RELAY

0026

0027

0028

0029

002A

002B

002C

002D

002E

002F Reserved

COMMANDS

0030

Command

Function Code

1 7 1

0031 Parameter 1 1 255 1

0032 Parameter 2 1 30 1

0033-

0048

Reserved

REAL TIME CLOCK

004C Date mm, dd 1, 1 12, 31 1, 1

004D yyyy 0 65535 1

004E Time hh, mm 0, 0 23, 59 1, 1

004F ssss 0 5999 1 • 0.01

(Continued)
