Event Analysis
Example Sequential Events Recorder (SER) Report
9.18
Example Sequential Events Recorder (SER) Report
This example SER report (Figure 9.2) corresponds to the event report in
Figure 9.1.
Figure 9.2 Example Sequential Events Recorder (SER) Event Report.
The SER event report rows in Figure 9.2 are explained in the Ta bl e 9.7 , numbered
in correspondence to the # column. The numbered comments in Figure 9.1 also
correspond to the # column numbers in Figure 9.2. The SER event report in Figure 9.2
contains records of events that occurred before the beginning of the event report in
Figure 9.1.
SEL-701 Date: 07/07/1999 Time: 14:50:04.744
MOTOR RELAY
FID=SEL-701-R100-V11Xxx-Z000000-D199907071 CID=1905
# DATE TIME ELEMENT STATE
13 06/07/1999 14:34:32.786 MOTOR_STOPPED ENDS
12 06/07/1999 14:34:32.786 MOTOR_STARTING BEGINS
11 06/07/1999 14:34:42.795 MOTOR_RUNNING BEGINS
10 06/07/1999 14:34:42.795 MOTOR_STARTING ENDS
9 06/07/1999 14:39:45.398 UNBALNC_I_ALARM PICKUP
8 06/07/1999 14:39:45.398 OUT1 Asserted
7 06/07/1999 14:39:47.907 UNBALNC_I_TRIP PICKUP
6 06/07/1999 14:39:47.907 TRIP Asserted
5 06/07/1999 14:39:48.007 UNBALNC_I_TRIP DROPOUT
4 06/07/1999 14:39:48.007 UNBALNC_I_ALARM DROPOUT
3 06/07/1999 14:39:48.007 OUT1 Deasserted
2 06/07/1999 14:39:48.028 MOTOR_STOPPED BEGINS
1 06/07/1999 14:39:48.028 MOTOR_RUNNING ENDS
