701 Motor Protection Relay Date Code 20010719
ASCII Serial Port Operation
Serial Port Automatic Messages
6.32
Serial Port Automatic Messages
When the serial port AUTO setting is Y, the relay sends automatic messages to
indicate specific conditions. The automatic messages are described in Table 6. 20.
Table 6.20 Ser ial Port Autom atic Messages
Table 6.20 Serial Port Automatic Messages
Condition Description
Power Up
The relay sends a message containing the present date
and time, relay and terminal identifiers, and the Access
Level 1 prompt when the relay is turned on.
Event Trigger The relay sends an event summary each time an event
report is triggered. See
Section 9: Event Analysis.
Self-Test Warning or Failure The relay sends a status report each time a self-test
warning or failure condition is detected. See
STATUS
Command Row & Column Definitions
on page 6.26.
