Schweitzer Engineering Laboratories SEL-701 - Table 7.10 120-Ohm Nickel RTD Type (Rtds 1-6)

To Next Page

To Previous Page

Date Code 20010719 701 Motor Protection Relay

Commissioning

Selected Functional Tests

7.17

Table 7.10 120- Ohm Nickel RTD Typ e (RTDs 1–6)

Table 7.11 120- Ohm Nickel RTD Typ e (RTDs 7–12)

Table 7.10 120-Ohm Nickel RTD Type (RTDs 1–6)

RTD Temperatures

Resistance

Value

(ohms)

Expected

Temperature

Reading

(°C)

Expected

Temperature

Reading

(°F)

1 2 3 4 5 6

86.17 –50 –58

120.00 0 32

157.74 50 122

200.64 100 212

248.95 150 302

303.64 200 392

353.14 240 464

Table 7.11 120-Ohm Nickel RTD Type (RTDs 7–12)

RTD Temperatures

Resistance

Value

(ohms)

Expected

Temperature

Reading

(°C)

Expected

Temperature

Reading

(°F)

7 8 9 10 11 12

86.17 –50 –58

120.00 0 32

157.74 50 122

200.64 100 212

248.95 150 302

303.64 200 392

353.14 240 464
