701 Motor Protection Relay Date Code 20010719
Installation
Panel Cut & Drill Plans
2.2
Figure 2.1 SEL-701 Relay
Mechanical Dimensions (Front and Top Views).
9.60 in
(243.8 mm)
7.00 in
(177.8 mm)
4.45 in
(113.0 mm)
0.77 in
(19.4 mm)
Terminal Block E
Terminal Block D
Terminal Block C
Terminal Block B
Terminal Block A (optional)
Captive Mounting Stud
(4 each)
Weather Gasket
