Schweitzer Engineering Laboratories SEL-701 - Figure 8.2 LDP Command Response

701 Motor Protection Relay Date Code 20010719
Metering & Monitoring
Load Profiling
8.8
=>ldp
SEL-701 Date: 08/26/1999 Time: 16:32:38.364
MOTOR RELAY
Record Number,Date,Time,Ia,Ib,Ic,In,% Thermal Capacity,% Current Unbalance,Frequ
ency,Winding RTD,Bearing RTD,Ambient RTD,Vab,Vbc,Vca,kW,kVAR,kVA
3,08/26/1999,16:00:00,190,192,191,0,69,0,60.0,150,112,78,458,460,457,156,44,162
2,08/26/1999,16:15:00,192,194,190,0,70,0,60.0,151,112,79,460,464,460,156,44,161
1,08/26/1999,16:30:00,190,190,192,0,69,0,60.0,150,111,78,458,462,463,156,44,162
=>
Figure 8.2 LDP Command Response.
