701 Motor Protection Relay Date Code 20010719

Commissioning

Selected Functional Tests

7.18

Table 7.12 100- Ohm Nickel RTD Typ e (RTDs 1–6)

Table 7.13 100- Ohm Nickel RTD Typ e (RTDs 7–12)

Table 7.12 100-Ohm Nickel RTD Type (RTDs 1–6)

RTD Temperatures

Resistance

Value

(ohms)

Expected

Temperature

Reading

(°C)

Expected

Temperature

Reading

(°F)

1 2 3 4 5 6

71.81 –50 –58

100.00 0 32

131.45 50 122

167.20 100 212

207.45 150 302

252.88 200 392

294.28 240 464

Table 7.13 100-Ohm Nickel RTD Type (RTDs 7–12)

RTD Temperatures

Resistance

Value

(ohms)

Expected

Temperature

Reading

(°C)

Expected

Temperature

Reading

(°F)

7 8 9 10 11 12

71.81 –50 –58

100.00 0 32

131.45 50 122

167.20 100 212

207.45 150 302

252.88 200 392

294.28 240 464
