CME M Command
D.29
CME M Command
Display Max/Min meter data in compressed ASCII format by typing:
CME M <CR>
The relay replaces the items in italics with the actual relay data.
The SEL-701 Relay sends:
<STX>"FID","yyyy"<CR>
"Relay FID string","yyyy"<CR>
"MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
"CHANNEL","MAX","DATE","TIME","MIN","DATE","TIME","yyyy"<CR>
"IA(A)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"IB(A)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"IC(A)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"IN(A)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"IG(A)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"VAB(V)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"VBC(V)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"VCA(V)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"VG(V)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"kW3P","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"kVAR3P","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"kVA3P","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
" 1 BRG (C)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
" 2 BRG (C)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
" 3 BRG (C)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
" 4 BRG (C)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
" 5 BRG (C)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
" 6 BRG (C)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
" 7 WDG (C)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
" 8 WDG (C)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
" 9 WDG (C)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"10 WDG (C)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"11 AMB (C)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"12 OTH (C)","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR>
"LAST RESET","yyyy"<CR>
"xxxx","yyyy"<CR>
<ETX>
Voltage and power labels are replaced with “*” if the optional voltage inputs are
not included. RTD labels are replaced with “*” if RTDs are not supported or enabled.
RTD locations and temperature designators are setting dependent.
