Schweitzer Engineering Laboratories SEL-701 - SEL-701 Relay Serial Number Label; Figure 1.3 SEL-701 Relay Serial Number Label

701 Motor Protection Relay Date Code 20010719
Introduction & Specifications
SEL-701 Relay Serial Number Label
1.10
SEL-701 Relay Serial Number Label
Figure 1.3 SEL-701 Relay Serial Number Label.
Figure 1.3 shows the serial number label for the SEL-701 Relay. The label is
affixed to the top of the relay chassis. From the top of the label, the information
includes:
 Relay part number.
 Relay serial number.
 Power supply ratings.
 AC current input ratings.
 AC voltage input ratings, or ‘None’ if voltage option was not ordered.
 Number of internal RTD inputs, either 11 or ‘None’.
PART NUMBER:
0701011XXX
S/N:
AMPS AC:
POWER SUPPLY:
VOLTS AC:
INTERNAL RTD INPUTS:
99166004
95–240 ±10% Vac 50/60 Hz
20–250 ±20% Vdc <15 VA
1A or 5A Nom 0–300 Vac
11
