Schweitzer Engineering Laboratories SEL-701 - Figure 6.17 TARGET Command Example; Table 6.17 TARGET Command Options

701 Motor Protection Relay Date Code 20010719
ASCII Serial Port Operation
Command Explanations
6.28
A Relay Word bit is either at a logical 1 (asserted) or a logical 0 (deasserted).
=>TARGET 1
STARTING RUNNING STOPPED JAMTRIP LOSSALRM LOSSTRIP 46UBA 46UBT
0 1 0 0 0 0 0 0
=>
Figure 6.17 TARGET Command Example.
The TAR command options are listed in Tab le 6.1 7.
Table 6.17 TARGET Comm and Option s
Table 6.17 TARGET Command Options
Commands Descriptions
TAR n k
Shows Relay Word row number n (0–11). k is an optional parameter
to specify the number of times (1–32767) to repeat the Relay Word
row display. If k is not specified, the Relay Word row is displayed
once. See
Table 6.18
for definition of Row 0. See
Table 6.19
for a list
of the Relay Word bits in each row (n = 1–10).
TAR name k Shows Relay Word row containing Relay Word bit name (e.g., TAR
50P1T displays Relay Word Row 3). Valid names are shown in
Table 6.18
. k is an optional parameter to specify the number of times
(1–32767) to repeat the Relay Word row display. If k is not specified,
the Relay Word row is displayed once.
