Schweitzer Engineering Laboratories SEL-701 - Figure 6.8 METER Command Example; Figure 6.9 METER D Command Example

701 Motor Protection Relay Date Code 20010719
ASCII Serial Port Operation
Command Explanations
6.16
=>METER
SEL-701 Date: 08/01/1999 Time: 15:59:15.739
MOTOR RELAY
A B C N G
I MAG (A, Fn) 69.74 69.85 69.61 0.00 0.33
(A,RMS) 69.66 69.77 69.62 0.02
I ANG (DEG) -45.08 -164.96 75.02 -156.51 -130.61
AB BC CA G
V MAG (V, Fn) 464 465 464 1
(V,RMS) 464 464 463
V ANG (DEG) 0.00 -120.08 119.85 -5.94
3P
kW (Fn) 54.14
kW (AVG) 54.09
HP (Fn) 72.57
kVAR 14.44
kVA 56.03
pf 0.97 LAG
Negative-Sequence Current Negative-Sequence Voltage
(3I2) (3V2)
MAG 0.07 1
ANG (DEG) 53.63 147.19
FREQ (Hz) 60.00
Unbalance (%) 0.1
=>
Figure 6.8 METER Command Example.
Demand Metering: METER D
The METER D command displays the demand and peak demand current values.
If the relay is equipped with voltage inputs, power demand and peak power demand
quantities are also included.
=>METER D
SEL-701 Date: 08/01/1999 Time: 15:59:26.490
MOTOR RELAY
IA IB IC IN IG 3I2
DEMAND 38.7 38.6 38.6 0.0 0.7 0.5
PEAK 40.5 41.3 41.8 0.1 2.4 2.1
kW3P kVAR3P-IN kVAR3P-OUT kVA3P
DEMAND 667.2 179.7 0.0 692.0
PEAK 681.6 183.7 0.0 704.1
LAST DEMAND RESET 07/02/1999 11:11:18.305
LAST PEAK RESET 07/02/1999 11:11:17.120
=>
Figure 6.9 METER D Command Example.
Energy Metering: METER E
When the relay is equipped with optional voltage inputs, the METER E
command displays the measured kilowatt hours, kilovar hours, and kilovolt-amp hours
since the last reset.
