Schweitzer Engineering Laboratories SEL-701 - Factory Default Logic Settings

Date Code 20010719 701 Motor Protection Relay
SELOGIC
®
Control Equations & Relay Logic
Factory Default Logic Settings
B.13
Factory Default Logic Settings
When you use the factory default logic by setting FACTLOG equal to Y, the relay
hides the logic settings and default settings shown below. Operation of these default
settings is described in Section 4: Settings Calculation.
If you set FACTLOG equal to N, the relay displays each of the settings in the
screen capture below. You can modify one or more of these settings to customize the
relay function. Descriptions of the functions controlled by the default settings are
included in the remainder of this appendix.
NOTE: If you change SELOGIC control equation settings, then
return the FACTLOG setting to Y, the relay will clear your
changes and resume using the factory settings shown below.
DISPLAY MESSAGE VARIABLES
DM1 =1
DM2 =1
DM3 =RTDFLT
DM4 =0
DM5 =0
DM6 =0
LOGIC VARIABLES
Logic Variable 1
SV1 =0
SV1 Pickup Time (0.00 – 3000.00 s) SV1PU=0.00
SV1 Dropout Time (0.00 – 3000.00 s) SV1DO=0.00
Logic Variable 2
SV2 =0
SV2 Pickup Time (0.00 – 3000.00 s) SV2PU=0.00
SV2 Dropout Time (0.00 – 3000.00 s) SV2DO=0.00
Logic Variable 3
SV3 =0
SV3 Pickup Time (0.00 – 3000.00 s) SV3PU=0.00
SV3 Dropout Time (0.00 – 3000.00 s) SV3DO=0.00
Logic Variable 4
SV4 =0
SV4 Pickup Time (0.00 – 3000.00 s) SV4PU=0.00
SV4 Dropout Time (0.00 – 3000.00 s) SV4DO=0.00
SET/RESET LATCH VARIABLES
Latch Variable 1
SET1 =0
RST1 =1
Latch Variable 2
SET2 =0
RST2 =1
Latch Variable 3
SET3 =0
RST3 =1
Latch Variable 4
SET4 =0
Continued on next page
RST4 =1
