701 Motor Protection Relay Date Code 20010719
ASCII Serial Port Operation
Command Explanations
6.22
Table 6.11 SE R Command O ptions
The date entries used with the SER command are dependent on the Date Format
setting. If the Date Format setting equals MDY, then the dates entered should have the
format mm/dd/yyyy. If the Date Format setting equals YMD, then the dates entered
should have the format yyyy/mm/dd.
If the requested load profile records do not exist, the relay responds “No
SER Data.”
SER R (Level 2)
SER R removes the SER data from nonvolatile memory.
SET (Level 2)
The SET command allows the user to view or change the relay settings.
Table 6.12 Ser ial Port SET Co mmands
When you issue the SET command, the relay presents a list of settings one at a
time. Enter a new setting or press <ENTER> to accept the existing setting. Editing
keystrokes are shown in Table 6.13.
Table 6.11 SER Command Options
Serial Port
Command
Description
SER Display all available SER records.
SER n Display the n most recent SER records, starting with record n.
SER n1 n2 Display SER records n2 to n1, starting with n2.
SER d1 Display all the SER records made on date d1.
SER d1 d2 Display all the SER records made from d2 to d1,
inclusive, starting with d2.
Table 6.12 Serial Port SET Commands
Command
Settings
Type
Description
SET Relay Protection elements, timers, etc.
SET R SER Sequential Events Recorder trigger
conditions and ALIAS settings.
SET P n Port Serial port settings for Serial Port n (n = F or R).
