701 Motor Protection Relay
Date Code 20010719
Commissioning
Selected Functional Tests
7.10
Figure 7.4 Two Voltage Source and Three Current Source Test Connections.
NOTE: Relays equipped with ac voltage inputs (Models 0701001X and 0701011X) must be properly grounded for accurate
voltage measurement.
+ –
VAB
IA
+ –
VCB IB
+ –
VIC
Two Voltage and Three Current Sources
E01
IA
E02 E04 E05 E07 E10 E11 D06 D07 D08 D09
IB IC IN VA VB VC N
Relay Phase Current (5A) and Voltage Inputs (DELTA_Y = D)
E08
D10
To Next Page
