701 Motor Protection Relay Date Code 20010719
Event Analysis
History Data & Event Summaries
9.6
If the event was stored in response to a rising edge of the TRIP SELOGIC control
equation, but the trip type doesn’t correspond to any of the trip messages in Front-
Panel Messages on page 9.4, TRIP will be the listed trip type.
Event Trigger Event Type
TRIGGER
Command TRIG
PULSE
Command PULSE
RISING EDGE
of
ER SEL
OGIC
control equation
ER
STOP
Command
STOP
COMMAND
