Schweitzer Engineering Laboratories SEL-701

To Next Page

To Previous Page

Date Code 20010719

701 Motor Protection Relay

SEL

OGIC

Control Equations & Relay Logic

Selected Relay Logic Diagrams

B.33

Figure B.11 Current Unbalance Element Logic.

Avg.

|IA|

|IB|

|IC|

lav

FLA

46UBA

46UBT

%UB = (|Iav-lm|/FLA) • 100%

Enable

%UB = (|Iav-lm|/lav) • 100%

46UBA

46UBT

Relay

Word

Bits

46UBAD

Settings

Max.Dev.

• 0.25

Enable

46UBTD

Inputs

IA =

IB =

IC =

FLA =

46UBA =

46UBT =

Avg. =

Iav =

Im =

46UBAD =

46 UBTD =

Phase Current

Full Load Amps Setting

Phase Current Unbalance Alarm Setting

Phase Current Unbalance Trip Setting

Average

Average Phase Current Magnitude

Magnitude of Current Having Max. Deviation From Iav

Phase Current Unbalance Alarm Delay

Phase Current Unbalance Trip Delay
