701 Motor Protection Relay Date Code 20010719

Modbus

RTU Communications Protocol

Modbus Register Map

C.22

Table C.18 Modbus Register Map (Continued)

Address

(hex)

Field

Sample

Low

High

Step

Type

RELAY ELEMENTS

0150

Latched

Targets, Row 1

0151 Rows 2, 3

0152 Rows 4, 5

0153 Rows 6, 7

0154 Rows 8, 9

0155 Rows 10, 11

0156–

015F

Reserved

RELAY STATUS

0160

Status

0 2047

0161

Status

0 511

0162–

016F

Reserved

INSTANTANEOUS METERING

0170 Ia Current 0 65535 1

0171 Ib Current 0 65535 1

0172 Ic Current 0 65535 1

0173

Average

Current

0 65535 1

0174 In Current 0 65535 1

0175 Vab Voltage

0 if no

voltage option

0 65535 1

0176 Vbc Voltage

0 if no

voltage option

0 65535 1

0177 Vca Voltage

0 if no

voltage option

0 65535 1

0178

Average

Voltage

0 if no

voltage option

0 65535 1

0179 Ia Rms Current 0 65535 1

017A Ib Rms Current 0 65535 1

(Continued)
