701 Motor Protection Relay Date Code 20010719
SEL-2020/2030 & SEL-701PC Compatibility Features
Fast Binary Message Definitions
D.12
Table D.6
A5C2/A5C3 Demand/Peak
Demand Fast Meter Configuration Messages (Continued)
Data Description
51332B000000 Analog channel name (Q3+)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
533300000000 Analog channel name (S3)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
51332D000000 Analog channel name (Q3–)
02 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
All Versions
00 Reserved
checksum 1-byte checksum of preceding bytes
