Date Code 010719 701 Motor Protection Relay
Date ___________
Created by ___________
Appendix F
SEL-701 Relay Settings Sheets
RELAY SETTINGS
General Data
Relay Identifier
Range: 20 Characters RID =
Terminal Identifier
Range: 20 Characters TID =
Phase (IA, IB, IC) CT Ratio
Range: 1-6000 CTR =
Phase CT Secondary Rating
Range: 1 A, 5 A ITAP =
Neutral (IN) CT Ratio
Range: 1-6000 CTRN =
Neutral CT Secondary Rating
Range: 1 A, 5 A INTAP =
Phase Rotation
Range: ABC, ACB PHROT =
Nominal Frequency
Range: 50, 60 Hz FNOM =
Date Format
Range: MDY, YMD DATE_F =
Demand Meter Time Constant
Range: 5, 10, 15, 30, 60 min DTMC =
Phase (VA, VB, VC) VT Ratio
(Hidden if voltages not included)
Range: 1-6000 PTR =
Phase VT Connection
(Hidden if voltages not included)
Range: D, Y DELTA_Y =
Single Voltage Input
(Hidden if voltages not included)
Range: Y, N SINGLEV =
