Date Code 010719 701 Motor Protection Relay
Date ___________
Created by ___________
OUTPUT CONFIGURATION
Analog Output Settings
Analog Output Signal Type
Range: 0–1 mA, 0–20 mA, 4–20 mA AOSIG =
Analog Output Parameter
Range: %Load_I Percentage of Full Load
Current
%THERM Percentage Thermal
Capacity
WDG_RTD Hottest Winding RTD
Temperature
BRG_RTD Hottest Bearing RTD
Temperature
AVG_I Average Phase Current
MAX_I Maximum Phase Current
AOPARM =
Analog Output Full Scale Current
(Only shown if AOPARM = AVG_I or MAX_I)
Range: 0.5–80.0 A; ITAP = 5 A
0.1–16.0 A; ITAP = 1 A
AOFSC =
Front-Panel Display Settings
Front-Panel Timeout
Range: 0–30 min FP_TO =
Front-Panel Display Brightness
Range: 25%, 50%, 75%, 100% FPBRITE =
Front-Panel Power Display
(Hidden if no voltage option)
Range: Y, N FP_KW =
Front-Panel RTD Display
(Hidden if RTDOPT = NONE)
Range: Y, N FP_RTD =
Front-Panel Display Message Settings
Display Messages
Range: 20 Characters; enter NA to null DM1_1 =
DM1_0 =
DM2_1 =
DM2_0 =
DM3_1 =
DM3_0 =
DM4_1 =
DM4_0 =
DM5_1 =
Page 13 of 17
