Schweitzer Engineering Laboratories SEL-701 - Page 463

Date Code 20010719 701 Motor Protection Relay
Index
IN.11
RTD location 4.31
RTD trip temperature
4.33
RTD type
4.32
send auto messages to port
4.50
SER alias settings
4.56
SER trigger settings
4.52
service factor
4.9, 4.11, 4.17
setting method
4.9, 4.11, 4.17
single voltage input
4.6
speed switch trip time delay
4.29
stop bits
4.50
temperature preference setting
4.30
terminal identifier
4.4
thermal capacity alarm pickup
4.21
thermal capacity used to start
4.21
time to trip
4.17
timeout
4.50
underpower element arming delay
4.39
use factory logic settings
4.46
use learned cooling time
4.22
use learned starting thermal capacity
4.21
VAR alarm time delay
4.38, 4.39
VAR element arming delay
4.38
VAR trip time delay
4.38
Short Circuit
See Overcurrent Elements
SHOW Command 6.24
Side Panel
diagrams 2.6
Specifications 1.11
Speed Switch
contact input 2.17, 2.17
control equation
B.27
logic diagram
B.42
tripping function
4.29
Start Motor
front-panel function 5.9
logic
B.23
STR command
6.27
Starting
See also Motor Start Report; Motor Start
Trend
current
8.12
average
8.9
LED indication
9.3
minimum voltage
8.12
average
8.9
thermal capacity
8.12
time
8.12
average
8.9
Starts Per Hour 4.25
lockout
B.21
meter
5.16, 6.17, 8.4
protection
4.25
STATUS Command 6.26
Status of Relay
See also STATUS Command
front-panel function
5.20
STOP Command 6.27
Stop Motor
front-panel function 5.9
STOP command
6.27
Stopped
LED indication 9.3
STR Command 6.27
TARGET Command 6.27
Target LEDs
definitions 9.2
diagram
5.1
reset
See Target Reset
viewed using TARGET command
6.29
Target Reset
front-panel function 5.10
reset targets
9.3
Tempe rature
See also Resistance Temperature Device
(RTD)
self-test
4.50
Terminal Emulation
default configuration 6.5
other programs
6.2
Test Signals
connection check 7.4–7.5
Thermal & RTD Meter 8.4
front-panel function
5.16
serial port command
6.17
