Schweitzer Engineering Laboratories SEL-734 - Page 238

A.8
SEL-734 Meter Instruction Manual Date Code 20090730
Firmware and Manual Versions
Instruction Manual
Appendix E
➤ Updated Analog Outputs information in Table E.5: DNP3 Device Profile.
Appendix H
➤ Updated Table H.7: Flicker Metering.
20090421
Section 4
➤ Updated Load Profile Report section to reflect up to 12 load profile records and 16 analog quantities.
➤ Added Imbalance Calculations and Average Calculations.
➤ Added power magnitudes P, Q, S, P_AVE, Q_AVE, and S_AVE and definitions to Table 4.1: Metering Quantity
Definitions.
Section 6
➤ Added information about new ACSELERATOR QuickSet interface for VSSI.
Section 9
➤ Added ITIC_ND, ITIC_PR, ITIC_SR, DSTCH, LOWBAT, and SETCH Meter Word bits to Table 9.3: SEL-734
Meter Word Bits.
➤ Removed DOWCH, HOLCH, ALTICH, ALT2CH, and SLFRD Meter Word bits from Table 9.3: SEL-734 Meter
Word Bits.
➤ Added ITIC_ND, ITIC_PR, ITIC_SR, DSTCH, LOWBAT, and SETCH Meter Word bits to Table 9.4: SEL-734
Meter Word Bit Definitions.
➤ Removed DOWCH, HOLCH, ALTICH, ALT2CH, and SLFRD Meter Word bits from Table 9.4: SEL-734 Meter
Word Bit Definitions.
Settings Sheets
➤ Added new Voltage Sag/Swell/Interrupt settings.
➤ Added new Load Profile Report settings.
Section 10
➤ Added Internal Modem information under Communications Options section.
Appendix A
➤ Updated for firmware version R130/R530.
Appendix E
➤ Added new Counter Inputs and Analog Inputs in Table E.5: DNP3 Device Profile.
Appendix F
➤ Added Load Profile addresses to Table F.23: Modbus Register Map.
Appendix H
➤ Added new analog quantities to Table H.1: Instantaneous and RMS Quantities.
➤ Added Table H.13: Transformer Ratio Settings.
Appendix I
➤ Moved Internal Modem information to Communications Options section in Section 6.
20090319
Command Summary
➤ Added SSI S command.
Table A.2 Instruction Manual Revision History (Sheet 2 of 2)
Revision
Date
Summary of Revisions
